Storage Solution – V9000 Unified Storage – 3Gen Data Systems

Overview

Storage Consolidation that can simultaneously meet your diverse needs - SAN and NAS, primary and secondary storage.

Unified storage platform supporting simultaneous block and file services for business and technical applications

3Gen Local and Network RAID with the most powerful RAID Engine on earth!

Dual Intel Xeon CPUs with speedy DPP RAID rebuild up to 5TB per hour

Upgradeable to 24 latest Fibre Channel and high speed Ethernet ports

Standard with 2 independent Gb Ethernet ports.

Storage Gateway option supports up to 1000 Storage nodes

Buy what you need today and grow when you need it in the future

Multi-Node support for maximum performance and failover protection

Unlimited scalability on computing power and storage capacity

Performance that meet your rigorous applications demands

Outstanding file and transaction based performance with high bandwidth, 64-bit architecture, and the latest I/O technologies

Speedy Natural Disaster Recovery via Global Clustering and Remote Volume Mirroring

Mirror critical data to local and remote locations via Fibre Channel and ISCSI

Value-added applications available for cloud computing, productivity and data availability

Dynamic thin provisioning, block level data de-duplication, real time Volume based encryption, WORM (Write Once Read Many), performance enhancing SSD and N+1 clustering to protect sensitive and mission critical data

Specifications

V9040/ V9040Pro , V9060/V9060Pro, V9080/V9080Pro, V9120Pro, V9160Pro, V9120ProDC (Dual Nodes) and V9240Pro (4 nodes) ( 2U, 3U and 4U) Unified Storage
Configuration
Operating System	3GenOS 64bit
CPU	V9000 Xeon E3-1220v6, V9000Pro Dual Xeon E5-2603 v4 and Xeon Scalable CPU optional
Memory	16GB ECC DDR4 Memory (up to 2TB)
Hard Drive Interface	Serial ATA III , SAS and NVMe
Maximum storage capacity	9000TB per node (with 12TB HDD)
High Performance SAS	6G / 12G
Connectivity
10/100/1000 Ethernet Ports	2 Auto-sensing (Up to 24)
Lastest FC & High Speed Ethernet	Optional (Up to 24 with V9080Pro, V9120Pro and V9160Pro)
NIC Teaming with LACP	Yes
Load Balancing	Yes
Ethernet Failover	Yes
Interoperability	Windows, Unix, Linux, Novell and MAC
Interface Support	iSCSI, FC, CIFS, NFS, HTTP, FTP, SMB, AD, LDAP, NIS, HDFS and S3/Openstack
Data Protection and Reliability
Hot or cold swap HDD	True Hot Swap
Online Volume Expansion	Yes
RAID	RAID 0, 1, 5, 6, 10, 50 and 60
SnapBack / SnapQuick	Yes
Local Volume Cloning	Yes
Redundant Cooling Fans	3 hot swappable
Redundant Power Supply	2 hot swappable
UPS and Environmental Support	Yes
Storage Gateway	Optional (up to 1000 storage nodes and HA up to 5 nodes failure)
File based Data De-Duplication	Optional
Block based Data De-Duplication	Optional
Dyanmic Thin Provisioning	Optional
Data Mirroring	Optional
Redundant OS	Optional
Performance SSD Caching	Optional
Active / Active Clustering	Optional
FileLock (WORM NAS)	Optional
FileLock (WORM NAS)	Optional
Real Time Volume Encryption	Optional
Management
Remote Management	Yes
Active Directory Services	Yes
Distributed Files System	Yes
Network Discovery Tool	Yes

DataSheet

High Value with unbeatable ROI

Today's business environment demands innovation and increasing flawless execution in all environments including virtualized computing. With 3Gen V9000 series Unified Storage, you have an ultimate all-in-one storage solution for handling block based storage, file serving, server consolidation, backup and restoration strategies, replication solutions, regulatory compliance data retention and the integration of NAS and SAN investments. Packed with enterprise features and protected with a 3 year warranty, 3Gen V9000 series delivers unsurpassed value with a price that is lower than all other storage solutions on the market

High Availability and Advanced Data Protection

All systems include hot swap technology and block level volume cloning software for maximum data protection. By connecting with another V9000 remotely via Gb Ethernet ports, backup and restore can be accomplished via our automated file based asynchronous remote mirroring and synchronous / asynchronous block based volume mirroring. V9000 incorporates SnapBack technology to reduce backup time to minutes; SnapQuick to enable recovery of point-in-time data in minutes. Furthermore, a full suite of optional enterprise software such as clustering (active-active and active-passive), WORM, real time volume encryption and remote synchronous data mirroring are available to protect your data

High Usability

3Gen V9000 series can be installed in just 15 minutes with plug-and-play network connectivity and intuitive installation tools. The web based management software allows users to manage their storage systems via web browsers from any place in the world. Thin Provisioning is available to eliminate stranded storage. Preserving investment in staff expertise and capital equipment is easy with 3Gen V9000 series because it is based on industrial proven 3GenNAS Operating System and management tools. While 3Gen's products are always on the cutting-edge, our customers can rest assured that easy-to-use stays on top of 3Gen's design philosophy. 3Gen is committed to bringing advanced Information Life Cycle Management features to all enterprises.

Storage Sharing and Access Control

With versatile 3Gen V9000 Unified Storage series systems, you can use high performance SAS, NVMe or large capacity SATA disk drives for optimal performance and cost ratio. 3Gen V9000 Unified Storage series can seamlessly consolidate block and file storage by providing native support for the FC, iSCSI, NFS and CIFS storage protocols.
